Slave Overdoor Light c/w Sounder
QT606S
- Provides audible and visual indication of calls made from a Quantec call point outside bedrooms, WCs, etc.
- Flash and sounder rates change/intensify to reflect the urgency of the incoming call.
- Dual red and green LEDs and triangular diffuser make it highly visible from a distance.
- Mounts on a standard UK 25mm single gang flush or surface back box.
- Finished in tough, durable ABS plastic.
- Also available as part of the QT951 Accessible Toilet Alarm kit.
| Quiescent current | Less than 1.5mA. |
| Alarm current | 40mA. |
| Indicators | Dual ultra-bright red and green Alarm LEDs (Flash rate and colour sequence changes/intensifies to reflect the urgency of the incoming call). |
| Connections | R (Red); G (Green); Net +; Net -. Wire as a slave to a Quantec Addressable Call Point or Accessible Toilet Reset Point. See instructions for details. |
| Onboard Sounder | Yes. (Sound sequence changes and intensifies to reflect the urgency of the incoming call). |
| Onboard Infrared Receiver | No. |
| Product dimensions (mm) | 87 W x 87 H x 54 D mm. Mounts on a UK 25mm single gang back box. |
| Construction & finish | Plastic. |
| IP Rating | IP41. |
| Weight | 58g. |
| Operating conditions/temperature | -5ºC to +40ºC. Max. relative humidity 95% non-condensing. |
