USB
StandardCorresponds to USB 2.0
RS-485
Speed300 bps .. 230.4 kbps300 bps .. 230.4 kbps
Maximum number of transmitters/receivers32 (limited line length and no terminating resistors)
Differential Output Voltage (TxD)3.3 V for RL=∞; min.: 1.5 V for RL=54 Ω
Receiver Input Impedance (RxD)12 kΩ
Minimum Input Voltage (RxD)0.2 V
Acceptable voltage in terminals A, B-7 .. +12 V (maks.)
Short circuit protectionYes
Other
PurposeFor service purposes only
Power supplyFrom the USB port
Rated current35 mA (no load on the RS-485 side)
USB / RS-485 galvanic isolationNe
Operating temperature0 .. +50 °C
Storage temperature-20 .. +60 °C
Dimensions (without terminals) L x W x H56 mm x 31 mm x 25 mm
Weight25 g
Other
VCP (for virtual COM PORT drivers)Windows 10 (32, 64 bit), Windows 8/8.1 (32, 64 bit), Mac OS-X, Linux 3.2 and newer
D2XX (for USB Direct drivers)Windows 10 (32, 64 bit), Windows 8/8.1 (32, 64 bit), Mac OS-X, Linux 2.6 and newer
